Industrial Process and Sensor: NoShok 1100 Series Diaphragm Type Differential Pressure Gauges

The NoShok 1100 Series Piston Type Differential Pressure Gauges are build to detect pressure drops between filters, pumps, strainers, valves and more. Available in 2 sizes, 2-1/2 inch and 4-1/2 inch

Precisely measures pressure drops across filters, strainers, separators, heat exchangers and applications where a higher level of solids are present in the measuring media<\\li>
High side is completely isolated from low side to prevent fluid movement between ports<\\li>
Maximum static or working pressure to 3,000 psi, 1,500 psi with brass housing<\\li>
2-1/2 and 4-1/2 inch sizes – top & bottom, or back connected<\\li>
Sensor housing is cast in a black anodized aluminum, 316L Stainless steel or brass and comes standard with a weather-resistant NEMA 4X enclosure and shatter-resistant acrylic lens<\\li>
Optional liquid filling lubricates gauge internals and extends service life by dampening the effects of vibration, pulsation and shock<\\li>
Convoluted diaphragm fully supported to the rated working pressure of the gauge<\\li>
Shipped with a certificate of calibration to ensure accuracy and quality performance<\\li>

NoShok Gauge Installation and Technical Manual: Click Here
